Detailing drawings

RebarCAD is used by small and large consultancies, rebar detailing groups, freelancers, precast manufacturers and contractors. From Terminal 5 at the UK’s Heathrow Airport to the Burj Tower in Dubai, RebarCAD has been used to detail the most complex of projects inside and outside India.

Case studies

Siddha WaterfrontSiddha Waterfront Project

The Siddha Waterfront Project is a large scale residential development 20 km from the centre of Kolkata. The completed development will consist of 18 G+14 storey residential buildings, that will contain over 1,500 flats.

The Grand Chola Hotel, ChennaiGrand Chola Hotel

This massive 6 billion Rupees project was India’s biggest greenfield hotel under construction and provides for 600 rooms. The 12 story structure is the new destination for luxury in the booming South Indian city of Chennai.

ApolloApollo OMR Multi-Speciality Hospital, Chennai

Apollo OMR Multi-Specialty Hospital is a specialist hospital in Chennai. It consists of 10 operating theatres, a purpose built intensive care unit which can accommodate 63 patients and 400 single patient rooms with en-suite bathrooms.

Hindustan Refinery

Hindustan Petroleum, Mumbai

The cost to upgrade HPCL’s lube oil base stock quality refinery near Mombai was INR 1030 Crores.HPCL operates one of the largest lube refineries in India with annual production of around 335 TMT of various Grades of API Group-1 LOBS having Sulphur above 300 ppm and saturates below 90%.

Magalore PetrochemicalMangalore Petrolchemical, Mangalore

The new petrochemical complex is expected to produce 900,000 metric tons per annum of para-xylene as well as about 275,000 MTA of benzene to support the growing demand for these petrochemicals in Asia.

Guru Gobind Singh Refinery, BathindaGuru Gobind Singh Refinery

Construction of Hydrogen Generation Unit for HMEL involved setting up two 44,000-TPA capacity hydrogen generation units (HGU) for HMEL’s grassroots refinery in Bathinda, Punjab.

In Salah Refinery, AlgeriaIn Salah Refinery

The finished gas plant handles 17 million cubic metres of gas, making it one of the biggest in the world. In addition, the plant boasts of a zero CO2 emission by having a capacity to store nearly 20 million tonnes of the pressurised greenhouse gas.

Saakaar KalptaruSaakaar Kalptaru, Bihar

The Saakaar Kalptaru project is a residential complex of apartments based in Begusarai. When complete the project will comprise
of 48,570ft and six storeys. The RCC framed structure will be earthquake resistant, with 5” thick infill brick panels.

Delhi One, DelhiDelhi One case study

The Delhi One Project is a mixed-use development currently under construction, incorporating residential, hospitality, leisure and business. The contemporary development will be a significant landmark in Delhi and consists of 9 multi storey towers ranging from 21 to 42 storeys.

Soba Meritta, ChennaiSoba Meritta, Chennai

This luxury gated community, spread across 6 acres of greenery, consists of 556 elegantly crafted apartments divided into 5 spacious blocks. Sobha wanted to start servicing the site with BBS for the first time ever and the
key challenge was to ensure accuracy and frugal consumption of reinforcement steel.

Sector 90, GurgaonSector 90, Gurgaon

The project was to build three 18 storey residential buildings. RebarCAD enabled the accurate calculation of the bar length and its weight based on IS codes.

MajhergaonMajhergaon Development, Kolkata

The Majhergaon Development is a luxury 5 storeyed residential housing project with 29 blocks near Badu Road in Madhyamgram, Kolkata. There are 730 hi-tech construction apartments set in 10 acres of clean, green, pollution free land. The complex includes a community hall, a banquet hall, a gymnasium and a swimming pool.

Chellagatta VillageChellagatta Village,Bangalore

The project was to build a 12 storey office building using a roller compacted concrete flat slab system. CADS provide the detailing software as well as technical support.

Salt Lake residential unitsSalt Lake, Kolkata

Manturam Realtors constructed G+3 & G+5 residential premises in Kolkata, SaltLake & New Town. It took approximately 12 month time to complete a project and used 150 tonnes of reinforcing steel.

SimplexNoapara-Dakshineswar Metro Project, Kolkata

A complex development that will ultimately extend the metro corridor from Noapara to Dakshinesar in Kolkata. The completed project will consist of an elevated metro viaduct, metro embankment, diversion of a 1.8km stretch of the Belgharia Expressway and construction of two metro stations.

Delhi MetroDelhi Metro Red Line, Ghaziabad, Uttar Pradesh

The project was to design and construct the elevated viaduct and 8 elevated stations, including the architectural finishing works of the stations, of Phase 3 of the Delhi MRTS. The Delhi Metro is expecting a ridership of 4 million after completion of this phase.
